*Most widely used in the world at present *Adopting DK core patented technology, ensures the stability and clarify of the prints *Adopting the updated temperature control system, has more than 10 times longer service life than previous temperature control watch(DK-1100A/B) *Adopting Industrial-grade key panel, can be used more than 300, 000 times(DK-1100A/B) *Adopting friendly and simple operation interfaces, ensures the user can learn to operate quickly.
Please contact us and tell us what products you want to pack. We will recommend the most suitable machine for you.
SYSTEM SOLUTIONS IN THE FIELD OF PACKAGING MACHINE
DESIGN CUSTOM THINK TANK MANUFACTURERS
Packaging & Shipping
It is an electronic continuous motion expiry date printer . It will product imprint on all common packaging materials at rates up to 300 prints per minute and at film speed up to 35meters per minute with below features:
* Most widely used in the world at present
*Adopting DK core patented technology, ensures the stability and clarify of the prints
*Adopting the updated temperature control system, has more than 10 times longer service life than previous temperature control watch(DK-1100A/B)
* Adopting Industrial-grade key panel, can be used more than 300, 000 times(DK-1100A/B)
* Adopting friendly and simple operation interfaces, ensures the user can learn to operate quickly.
Print Area | Axial=40mm; Radial=45.5mm |
Printing Lines | T-type (Axial) up to 13lines, max 20characters per line |
R-type (Radial) up to 10lines, max 13characters per line | |
Font Size | T-type 1.5mm, 2.0mm, 2.5mm, 3.0mm*3.5mm |
R-type 3.5mm*3.5mm, 4.5mm, 5.5mm | |
Cycle Rate | up to 300 prints/minute |
Surface Speed | up to 35 meters/minute |
Pouch Length | ≥38mm (4-up printer) |
≥75mm (2-up printer) | |
Type of Print Head | Right-hand (Clockwise) |
Left-hand (Counter-clockwise) | |
Control Box | LED display |
Ink Roll Required | ¢36*40mm |
Electrical | AC100-230V, 50/60Hz |
Power | 130W, 2A Fuse |
Enviromental Operating Temperature | 4°c-40 °c |
Relative Humidity | 10%-95% |
Weight | Print Head 2.0kg Control box 1.0kg |
Dimensions | Print Head 120mm*100mm*170mm (L*W*H) |
Ctrol Box 180mm*180mm*102mm (L*W*H) |
