Servo feed, accurate, easy to adjust. Self compensation servo motor, photoelectric tracking precision fast do not waste film, reduce the cost Directly heating type longitudinal sealing, the sealing is more strong and beautiful. Differential feed, adjust without stopping. The machine stainless steel casing, the dean health more in line with food hygiene standards.
Please contact us and tell us what products you want to pack. We will recommend the most suitable machine for you.
Standard style
SYSTEM SOLUTIONS IN THE FIELD OF PACKAGING MACHINE
DESIGN CUSTOM THINK TANK MANUFACTURERS
Packaging & Shipping
Applicable:
Usage: Applicable for packaging of vadous large and regular objects like biscuit. bread. vermicelli, commodities. large-pack paper tissue. napkin, industrial parts, paper box or tray.
Main performance and structure characteristics
Servo feed, accurate, easy to adjust.
Self compensation servo motor, photoelectric tracking precision fast do not waste film, reduce the cost
Directly heating type longitudinal sealing, the sealing is more strong and beautiful.
Differential feed, adjust without stopping.
The machine stainless steel casing, the dean health more in line with food hygiene standards.
Technical parameter:
Packing size | L80-350 W30-200 H5-80mm |
Maximum width of film | 480 |
Thickness of film | >0.025 mm |
Total power | 3.5KW |
Rated voltage | 220V |
Rated frequency | 50HZ |
Weight of the machine | 700KG |
Overall size | 4700*940*1520 |
Technical parameter comparison:
Machine model | ||
Number of major electrical appliances | Servo motor *3, driver *3, | Servo motor *1, driver *1, deceleration motor *1, |
Machine size | L450*W94*H185 | L450*W94*H152 |
Main body material of the fuselage | Stainless steel | Stainless steel and aluminum alloy |
Weight | 650kg | 600kg |
Voltage power | 220v. 50Hz | |
Packaging size | 500mm | |
Packaging speed | 25-200 bags / minutes | 25-200 bags / minutes |
Driving mode | 3 servo motor drive | Single servo motor + ordinary deceleration motor |
Stop the empty package function | yes | no |
Automatic reset function | yes | no |
Install a compound shaper | Standard configuration | Can (add money selection) |
Automatic opening and closing of air seal | yes | no |
Automatic alignment of bearing film shaft | Standard configuration | Can (add money selection) |
Rotary hanger | Standard configuration | no |
Alcohol spray atomizer | Standard configuration | Can (select) |
Matching aeration structure (excluding nitrogen charging system) | Standard configuration | Can (select) |
Can directly match the automatic material packing line of material delivery | yes(can be directly linked to the data line to implement a single machine and | no |
Equipment maintenance cycle | Change the transmission belt (half a year. One year) | Weekly (after three shifts, transmission gear chain, etc.). |
